Telephone cable

Get a Price/Quote

Telephone cable Specification

Conductor Shape
Round

Core Number
2, 4, or as required

Rated Temperature
-10°C to +70°C

Tensile Strength
13.7 MPa (PVC jacket)

Insulation
High-grade PVC

Core Material
Copper

Operating Temperature
-10°C to +70°C

Usage & Applications
Telecommunication, telephone lines, intercoms, fax machines

Conductor Type
Solid, multi-stranded (option available)

Weight
5-10 kg per roll (depends on length)

Armored Material
Not armored (standard)

Cable Type
Telephone Cable

Install Type
Indoor, outdoor duct installation

Number of Conductor
2, 4, or as specified

Diameter
4.8 mm ± 0.2 mm (for 2-core, varies with spec)

Impedance
100 Ohm (typical)

Dielectiric Strength
1.5 kV min

Product Type
Cable

Length
Customizable (e.g., 100m, 200m rolls)

Voltage
Up to 300V

Insulation Material
PVC

Application
Telephone line connection, telecommunication networks

Conductor Material
Copper

Jacket Material
PVC

Storage Temperature
-20°C to +70°C

Shield Material
Unshielded (standard), can be customized

Jacket Color
White, Grey, Black (standard)

Dimension (L*W*H)
Varies (based on roll size)

Material
Copper, PVC

Color
White, Grey, Black

Size
0.4 mm/0.5 mm conductor diameter (standard options)

RoHS Compliance
Yes

Minimum Bending Radius
5 x cable diameter

Insulation Resistance
1000 M/km

Flame Retardant
Yes, compliant with IEC 60332

Packaging
Standard rolls, wooden drum, or as requested

Capacitance
52 pF/m

Frequency Range
Up to 1 MHz

Attenuation
1.5 dB at 1 MHz

Surface Finish
Smooth

Telephone cable About

Discover our immaculate Telephone Cablea ravishing solution for telecommunication needs, now available in limited stock. Supporting attenuation of 1.5 dB at 1 MHz, flame retardancy per IEC 60332, and RoHS compliance ensure both safety and reliability. Freshly manufactured with a smooth surface finish, this cable is crafted from solid or multi-stranded copper conductors and high-grade PVC insulation. Available in multiple core counts and customizable lengths, buy online now to guarantee uninterrupted connectivity for your telecommunication networks. Noteworthy quality, featuring superior insulation resistance and a pristine appearanceperfect for modern infrastructures.

Wide Application Areas for Every Connection

This Telephone Cable is engineered for versatility, making it ideal for a spectrum of applications. From telephone lines and intercoms in residential or business settings to comprehensive telecommunication networks, its usage spans both indoor and outdoor duct installations. With its robust build and superior electrical performance, it seamlessly integrates into offices, apartment complexes, commercial hubs, and industrial sites, ensuring reliable communication wherever required.

Premium Supply, Sample Availability, and Nationwide Drop-Off

Samples of our premium Telephone Cable are available for evaluation before bulk orders. With a high supply ability to meet diverse requirements, each roll is carefully shipped to ensure it reaches your location securely. We offer a swift drop-off across India, focusing primarily on the main domestic market, enabling timely installations and minimizing project downtime for our valued customers.

FAQs of Telephone cable:

Q: How do I order customized lengths or conductor options for your telephone cable?

A: You can specify your desired length (such as 100m or 200m rolls) and conductor type (solid or multi-stranded, as well as the core number) when placing your order. Custom requests are accommodated to meet various installation requirements.

Q: What are the main application benefits of this telephone cable?

A: This cable offers low attenuation and high insulation resistance, making it excellent for reliable data transmission in telephone lines, telecommunication networks, intercoms, and fax connections. Its flame retardancy and RoHS compliance provide added security and environmental responsibility.

Q: Where can these telephone cables be installed?

A: These cables are designed for both indoor and outdoor duct installations, making them suitable for offices, residential complexes, commercial environments, and industrial facilities.

Q: What is the process for requesting a product sample before making a bulk purchase?

A: Simply contact our sales team to request a telephone cable sample. We will arrange shipment for your evaluation, ensuring you can verify product quality before placing a larger order.

Q: When can I expect shipping and delivery after ordering online?

A: Once the order is confirmed, standard rolls are shipped promptly, with delivery timelines depending on the location. We offer efficient drop-off across key domestic markets to ensure timely project execution.
